Aermacchi MB339-CB



Taken at Whenuapai, March 17, 2001. Rear fuselage - port side aft of the wing. A number of panels are open - closest at the top contains a blowoff valve with the No1 battery beyond. the lower panel gives access to the weapons inventory panel, a circuit breaker panel, and the control units for the No1 and No2 generator. A view of the closed panels can be seen in W01MAC31.
